Materials Preparation

Main specifications

1. Maximum automatic cutting capacity: cutting diameter not less than 40mm (Y-axis);

2. Total power: not less than 0.75 kW; Cutting power: not less than 0.37 kW;

3. Cutting wheel speed range: not less than 300-3000rpm;

4. Cutting wheel specification: not less than 75-203mm diameter;

5. Automatic Y-axis (vertical up and down direction) travel: not less than 120 mm manual/automatic, automatic Y-axis (vertical up and down direction) feed rate: not less than 0.01-20 mm/s;

6. Z-axis (parallel sequence cutting) stroke: not less than 25 mm, manual, Z-axis (horizontal left and right direction) accuracy: 0.005 mm;

7. Shaft diameter size: Ø 12.7 mm;

8. It has four cutting modes: manual cutting (handle), automatic feed feeding, grinding mode, and cutting with workbench accessories;

9. Store 200 custom cutting programs; The software includes a consumables database to provide application references for operators, and sets maintenance and upkeep tasks in the software, including automatic reminders;

10. Provide two types of cooling systems, namely immersion cooling (built-in) and 15L external circulating cooling system;

11. It has the function of setting different levels of user permissions separately, and the emergency stop button is designed in a prominent position on the panel to ensure the safety of machine use;

12. It can achieve manual cutting of sheet type samples and oversized samples (sample height not exceeding 40mm);

Main functions

Cutting samples within a certain size range
